ImmoServiceTool PIN and Key Data Calculator for ECU and Cluster Jobs 1009

ImmoServiceTool is a workshop utility for working with immobilizer related data during authorized service and module replacement. It helps calculate service values from ECU, dashboard, or body module memory dumps and organizes coverage by brand, model, module type, controller vendor, CPU, and EEPROM family.

The database style list is designed to speed up common jobs like key matching, ECU to cluster pairing, and recovering correct security data after a module swap, when performed under valid authorization and proof of ownership.


Highlights

• Searchable database by brand and model with controller vendor and part type labels
• PIN focused entries for ECUs, dashboards, and body modules depending on platform support
• Module level grouping by manufacturer such as Bosch, Siemens, Delphi, VDO, Sagem, Valeo, Johnson Controls, Magneti Marelli, Visteon
• Hardware hints for CPU and EEPROM families to reduce wrong file selection
• Job oriented workflow with a single action button after selecting the correct entry

Package contents

• ImmoServiceTool.exe
• msvc2017.dll
• msvcp120d.dll
• msvcr120d.dll
• softwarelog.txt

Compatibility notes
Coverage is database driven and depends on the exact module type and memory layout. Availability varies by vehicle and firmware.


Use the EEPROM and CPU columns as a quick validation step before any calculation. If the module memory does not match the listed EEPROM family, results may be incorrect.

Basic usage

1. Launch ImmoServiceTool and confirm it opens without missing runtime files
2. Find the correct brand and model, then select the matching module entry
3. Verify controller vendor and EEPROM family match your readout
4. Use the tool output only within authorized OEM diagnostic and security procedures
5. Document the job and verify system operation with a full diagnostic scan

Operating systems
Windows PC environment is required. Most workshop builds of this type are used on Windows 7 to Windows 10.

Disclaimer
For lawful service only. No keys, no bураss methods, and no instructions for defeating security systems. Use only with valid authorization and proof of ownership.
