Overview
A practical reference for bench connections in EGPT service mode on Bosch MEDC17/EDC17/MEV17 ECUs. The tool aggregates color-coded cable maps, CAN/K-Line/GPT pin definitions and brand-specific connector diagrams to speed up safe bench programming and diagnostics.



Highlights

• EGPT service mode hub with Cable Pinout and Cable Preview for quick harness checks
• Color map for cable types: 12V+, GND, CAN H/L, K-Line, GPT0/GPT1, CNF1, VPP, BOOT
• Visual pin overlays for popular ECUs (e.g., EDC17C49, EDC17C50, EDC17CP27, MEV17.4.2)
• Make/model browser covering ALL BRAND plus BMW/MINI, VAG, Mercedes, PSA, JLR, FCA, Ford, Kia/Hyundai, Toyota, Volvo and more
• Cross-references to PCMFlash module PDFs for method selection and safety notes
• Offline, read-only reference for bench/boot preparation and harness building

Package contents
Application

• MEDC17_EGPT_Pinout_Tool_v1.4.exe

Built-in visuals

• Cable Pinout (Type 1 / Type 2 color tables)
• Cable Preview image of EGPT multi-lead harness
• Connector pages with overlays: CAN H/L, GND, +12V, GPT0/GPT1, BOOT, CNF1

EGPT Pinout Database — PCMFlash Modules

• Folder: PCMFLASH S7 MODULE
• Files included (selection exactly as in pack): pcmflash_01.pdf, pcmflash_07.pdf, pcmflash_10.pdf, pcmflash_16.pdf, pcmflash_21.pdf, pcmflash_26.pdf, pcmflash_28.pdf, pcmflash_29.pdf, pcmflash_30.pdf, pcmflash_31.pdf, pcmflash_34.pdf, pcmflash_36.pdf, pcmflash_37.pdf, pcmflash_39.pdf, pcmflash_41.pdf, pcmflash_42.pdf, pcmflash_51.pdf, pcmflash_52.pdf, pcmflash_53.pdf, pcmflash_55.pdf, pcmflash_57.pdf, pcmflash_59.pdf, pcmflash_60.pdf, pcmflash_61.pdf, pcmflash_62.pdf, pcmflash_63.pdf, pcmflash_64.pdf, pcmflash_67.pdf, pcmflash_69.pdf

EGPT Pinout Database — 2777 Pinout (large PDF library)

• Examples visible in the pack: AGCO_AUTOS_CONTROL_UNIT.pdf, AURIX_TC297_DCM7.1_PSA.pdf, BAM_MPC5566_CONTINENTAL_EMS58_.pdf, BAM_SPC5674_DELPHI_DCM6.2_KIA.pdf, BDM_HC12_PROCESSOR.pdf, BENCH_AURIX_BENTLEY_MG1CS163_TC29xx.pdf, BENCH_AURIX_BMW_MD1CP032_TC299xx.pdf, BENCH_AURIX_BMW_MD1CS001_TC29xx.pdf, BENCH_AURIX_FORD_MG1CS016_TC275xx.pdf, BENCH_AURIX_HYUNDAI_MD1CS012_TC29xx.pdf, BENCH_AURIX_LAND_ROVER_MG1CS20x_TC29xx.pdf, BENCH_AURIX_NISSAN_MD1CS006_TC29xx.pdf
• Total PDFs in folder: extensive multi-brand coverage for EDC17/MEV17/MD1/MG1 and AURIX generations

Compatibility notes
Diagrams target Bosch MEDC17/EDC17/MEV17 families and related AURIX MD1/MG1 units. Pin layouts and service points vary by ECU hardware, software revision and vehicle wiring. Always validate against the exact ECU part number and compare with your tool vendor’s procedure. Availability of GPT/BOOT points can differ across markets and firmware.

Basic usage

• Open the tool and select EGPT SERVICE MODE → CABLE PINOUT to confirm harness colors and GPT mapping
• Browse by CAR BRAND or ECU to view annotated connector images with 12V, GND, CAN H/L, GPT0, GPT1, BOOT and CNF1
• Cross-check with the included PCMFlash module PDF to confirm read/write method and cautions
• Prepare a clean bench power supply and verified backups before any operation
• After work, reassemble carefully and perform a controlled test with fault-code review
