PCMflash Bench Kit is a practical package for ECU bench work. It combines a preconfigured PCMflash v1.2.0 installer, module 71 bench wiring diagrams and a large virtual read file library for reference and recovery jobs.
Highlights
- Bench wiring diagrams for module 71 to speed up safe connections
- 15 GB virtual read (VR) file library for identification and reference
- Preconfigured installer designed for quick setup
- Included Guardant driver package for dongle communication
- Compact toolkit suitable for workshop and lab use
Package contents
- PCM BENCH 71 WIRING DIAGRAM
- VR FILES MEGA DOWNLOAD 15 GB
- binunlock.com
- GrdDrivers.exe
- PCMflash_1.2.0_Installer_No_activation.exe
Compatibility notes
Focus is on ECUs supported by PCMflash module 71 bench connection methods. Actual support depends on ECU family, hardware index and harness quality. Use VR files only as reference to match IDs and calibrations.
Basic usage
- Install Guardant drivers using GrdDrivers.exe
- Review the bench wiring diagram and prepare a stable power supply
- Connect the ECU on the bench following the diagram notes
- Use PCMflash to identify the ECU and validate against the VR library
- Document operations and keep original data backups
Operating systems
- Windows: 7, 8.1, 10, 11 • Architectures: x86 and x64
- macOS: via virtualization if required • Chips: Intel and Apple Silicon
Minimum system requirements
CPU: dual core • RAM: 4 GB • Storage: 25 GB free for VR library • Network: optional for cloud storage access • Admin rights: required.
Disclaimer
* Source of Files. All software and resources in this post are collected from public and open sources on the internet. We do not claim authorship or ownership.
* File Hosting. This forum does not host files. All links point to third party public cloud storage. We are not responsible for external content.
* User Responsibility. Software is provided for educational and evaluation purposes only. You use it at your own risk. Authors of the post and forum administration are not liable for any damage.
