WABCO TEBS-E eDiagnostic is a Windows service application for ZF WABCO trailer braking systems. It helps technicians connect to TEBS-E ECUs, read faults and parameters, run service routines and manage authorized PIN workflows using supported workshop interfaces.
Highlights
- Two builds included: v7.00 and v7.20 for wider ECU compatibility
- DTC read and clear with live measured values and status screens
- Service functions for calibration, configuration and maintenance tests
- Authorized PIN handling utilities for protected operations
- Designed for use with WABCO WD-USB and compatible workshop adapters
Package contents
- TEBS-E v7.00PIN.exe
- TEBS-E v7.20PIN.exe
- Screenshot_4.png
Compatibility notes
Intended for WABCO trailer EBS controllers of the TEBS-E generation. Function availability varies by ECU index, firmware and vehicle wiring. Adapter support depends on driver and interface firmware. Always follow OEM procedures and regional regulations.
Basic usage
- Install the selected version and connect a supported WD-USB or RP1210/J2534 adapter
- Establish communication with the TEBS-E ECU and save a baseline fault report
- Review live values and run only the maintenance routines specified by service literature
- Use PIN features strictly for authorized operations with valid codes
- Export reports and back up configuration before any change
Operating systems
- Windows: 7, 8.1, 10, 11 • Architectures: x86 and x64
- macOS: usable via virtualization on Intel or Apple Silicon if required
Minimum system requirements
CPU: dual core or better. RAM: 2 GB. Storage: 1 GB free. Display: 1366×768 or higher. One USB port for the interface. Local administrator rights recommended. Stable 24 V trailer power during diagnostics.
