I follow this instruction exactly, but STEP 5 i get lost. Any options to add registy key wont appear.
Any advice?
Thanks.

BMW ISTA‑PLUS 4.57.30 — Installation & Setup Guide

Important notes:
  • Run as administrator only.
  • OS: Windows 10/11 x64.
  • Standalone operation (no need for standard tools or EDIABAS).

Step 1. Extract main archive
1. Unpack ISTA.rar to:
C:\ISTA\

Step 2. Create shortcut
1. Make a desktop shortcut for:
C:\ISTA\TesterGUI\bin\Release\ISTAGUI.exe

Step 3. Extract config data
1. Go to:
C:\ISTA+4.57.30\config\
2. Unpack BMW.rar to:
C:\ProgramData\

Step 4. Set system variables
1. Run as admin:
ISPIDATA System Variables

Step 5. Select operation mode

Option A. Diagnostics only
1. Add registry key:
ISTA+ 4.57.30 diagnostic only

Option B. Full programming
1. Add registry key:
ISTA+ 4.57.30 full programming

Note: All required data is included (no extra lite data needed).
Click to expand...

Step 6. Install PSDZdata (for programming)
1. Download full PSDZdata pack (e.g., from:
https://binunlock.com/resources/psdzdata-full-ecu-programming-data-pack-for-e-sys.229/)
2. Extract to:
C:\ISTA\PdZ\data_swi\

Step 7. D‑CAN interface setup
1. Before launching ISTA, go to:
C:\ISTA\tool\
2. Run:
Switch ICOM-ENET or DCAN (com3)
3. Press any key to select interface.
4. Set parameters:
- Interface: COM3
- Latency timer: 1

To revert to ICOM‑ENET: run the switch again and press any key.
Click to expand...

Final steps:
1. Always launch ISTA as administrator.
2. System is ready for use.

Warning:
  • This is the latest version, not fully tested.
  • Exercise caution when programming ECUs.

Sort by date Sort by votes
Juhnu said:
I follow this instruction exactly, but STEP 5 i get lost. Any options to add registy key wont appear...
Click to expand...

Hey,

Step 5 is referring to .reg registry files that should have been included in the original download package (usually inside the C:\ISTA+4.57.30\config\ folder or a similar subfolder). They are typically named something like:

  • ISTA+ 4.57.30 diagnostic only.reg
  • ISTA+ 4.57.30 full programming.reg

What to check:

  1. Go back to your extracted archive and look through all subfolders — especially config, tools, registry, or reg folders — for .reg files.
  2. If you find them, right-click → Run as administrator → confirm the merge into registry.
  3. If the .reg files are simply missing from your download, then the archive you got is incomplete. You'll need to re-download the full package or find the missing registry files separately.

If you can't find the .reg files at all:

You can create them manually. The typical registry entries for ISTA+ 4.57.30 standalone mode go under:

Code:
HKEY_LOCAL_MACHINE\SOFTWARE\WOW6432Node\BMWGroup\ISPI\ISTA

Key values usually include things like:
  • DataPath — pointing to your ISTA data folder
  • IconPath — path to ISTA icons
  • PdZDataPath — path to PSDZdata (for programming mode)
  • OperationMode — value that switches between diagnostic-only and full programming

However, the exact values and keys depend on the specific rераск you downloaded. Guessing wrong here can cause ISTA to not launch at all.

My advice:

  1. Double-check every folder in your extracted archive for .reg files — use Windows search for *.reg inside the ISTA folder tree.
  2. If they're truly missing, post back with a screenshot or list of what's inside your config folder and the root of the archive, and we can help you figure out what's missing.
  3. Also mention where exactly you downloaded this package from, so someone with the same version can confirm the correct file structure.

Upvote 0 Downvote
Juhnu said:
I have reg files yes but instruction advices me to choose operation mode first in step 5. How?
Click to expand...

Ah, I see what you mean now — the guide says "Add registry key" and lists two options (A or B), but doesn't explain how to actually choose between them. It's simpler than it looks:

You just pick one and double-click the corresponding .reg file:

  • Option A — Diagnostics only: Double-click the .reg file named something like ISTA+ 4.57.30 diagnostic only.reg
  • Option B — Full programming: Double-click the .reg file named something like ISTA+ 4.57.30 full programming.reg

That's it — there's no separate menu or UI to "select" the mode. The .reg file is the selection. It writes the appropriate registry values that tell ISTA which mode to run in.

Steps:
  1. Decide what you need — if you only need to read codes/diagnostics, go with Option A. If you need ECU coding/programming (and you have PSDZdata from Step 6), go with Option B.
  2. Right-click the matching .reg file → Run as administrator
  3. Click Yes when Windows asks to confirm the registry merge.
  4. Done — move on to Step 6 (if you chose full programming) or Step 7.

Note: You can always switch later by running the other .reg file — it will just overwrite the previous registry values.

Upvote 0 Downvote
